1.Main parameters：

1.1. Power Input:3KW 380V.

1.2.Roller motor for principle axis: 0-1500RPM 0.75KW.

1.3.Height adjust motor speed: 0-1440RPM 0.55KW.

1.4.Cutting speed: 1.0-5.0M/min.

1.5.Air Input: 0.4-0.7MPa.

1.6.External Dimensions LxWxH: 5000mm x 2230mm x 1300mm.

1.7.Max. sheet loaded LxWxH: 1300mm x 1300mm*80mm.

2.Main configuration:

2.1.Gear e-reducer: Taiwan Shengbang 2sets*0.55W

2.2.Low-voltage apparatus: 1 set*Schneider

2.3.Encoder: OMRON for digital control of all dimension

2.4.Lead screw slideway: Taiwan HIWIN 2sets

2.5.Pneumatic control: Taiwan AirTAC 1 sets

2.6.Forming blade 1 sets

2.7.MITSUBISHI operation system

2.8 .Power cable：3*2.5+1
