1. Main parameters：

 1.1.Power Input: 380V 20KW.

1.2.Speed of machine shaft: 3000RPM *8 motors.

1.3.Air Input: 0.4-0.7 MPa.

1.4.External Dimensions LxWxH: 4200mm x 1550mm x 1700mm.

1.5.Max. Sheet loaded LxWxH：2500mm x 1300mm x 80mm.

1.6.Hole-Hole Spacing Options: 20*20/40*40/20*40, 孔径 Ø1-4mm.

1.7.Feeding length & perforation depth adjustable thrum servo.

1.8.Parameters/functions adjustable via touch screen.

1.9.Speed:1.5-2Min/Pcs

1.10. Purpose：Foam & Balsa perforation for Infusion.

2. Recommended cable :3*10 1
