1. Main parameters：

1.1.Power Input:30KW 380V.

1.2. Main Motor speed: 0-1500RPM 1.5KW.

1.3 .Height adjust motor speed: 0-1440RPM 1.5KW.

1.4. Oil heating system: 30KW.

1.5. Air Input: 0.4-0.7MPa.

1.6. External Dimensions LxWxH: 3600mm x 2360mm x 2300mm.

1.7. Max. sheet loaded WxH: 1300mm x 100mm.

Main configuration of equipment

2.1 Gear e-reducer: Taiwan Shengbang 2sets*1.5W

2.2 Low-voltage apparatus: 1 set*Schneider

2.3 Encoder: OMRON for digital control of all dimension

2.4 Lead screw slideway: Taiwan Shangyin 10 sets

2.5 Pneumatic control: Taiwan AirTAC 1 sets

2.6 Fabric tension control: Taiwan TRC1 sets

2.7MITSUBISHI operation system

2.8 Power cable：3*16+1
