Main parameter：

Power Input (KW):45, Control Voltage (V) 380V.

Main Motor speed: 0-2500r/min;15KW*5.

Feeding Servo Motor speed:0-2000r/min;1.3KW.

Height adjust Servo Motor speed:0-2000r/min;1.3KW.

The saw blade tension by air cylinder, Can easy adjustment.

Air pressure (bar): 0.4-0.7mpa.

Dimensions LxWxH: 7850X3750X3250mm;

Capacity LxWxH：3000X1300X1250mm;

Saw blade spec.: L7660*W32*H1.3MM.

Application：Slit the PVC，PET，PMI， PI or Balsa block to Sheets.

Parameters/functions adjustable via touch screen.

The product is secured to the work surface by vacuum suction.

Slice thickness: 2–300 mm.

Cutting accuracy: ±0.2 mm.

Cutting speed: 0–10 m/min.
