1.Main parameters：

1.1. The total power of the machine is 32 kilowatts, and the power supply is 380 volts,

1.2.  Speed of machine shaft: 3000RPM *10 motors.

1.3.  Air Input: 0.4-0.7 MPa.

1.4.  External Dimensions LxWxH: 3000mm x 2200mm x 2520mm.

1.5. Max. Sheet loaded LxWxH：1300mm x 1300mm x 300mm.

1.6. Hole-Hole Spacing Options: 20*20/40*40/20*40, 孔径 Ø1-4mm.

1.7. Feeding length & perforation depth adjustable thrum servo.

1.8. Parameters/functions adjustable via touch screen.

1.9.Speed:5-8Min/Pcs

1.10. Purpose：Foam & Balsa perforation for Infusion.

2.Cable is recommended:3*16+1
