1.Main parameters：

1.1.Power Input: 380V 27KW.

1.2.Motor spindle speed：0-6000M/min.

1.3.Air Input: 0.4-0.7 MPa.

1.4.External Dimensions LxWxH:3700mm x 2350mm x 2200mm.

1.5.Max. Sheet loaded WxH：1350mm x 100mm.

1.6. Servo motors control the thickness of the material.

1.7. Parameters/functions adjustable via touch screen.

1.8. It is characterized by continuous cutting, easy flow operation, high precision (± 0.1) mm.

1.9. It is suitable for processing foamed core board and Light Wood quadrangle.

2. Equipment Configuration:

2.1. High-speed electric spindle motor: 4 sets of 4.5 kw * ;

2.2. Low-voltage electrical appliances: Schneider * 1 set;

2.3. Servo motor full digital control dimensional accuracy;

2.4. Screw Slide: 3 sets of Taiwan Silver;

2.5. Pneumatic control system: 1 set for Jade, Taiwan;

2.6. Taiying precision planetary servo reducer;

2.7. Operation and control system: 1 set for Citroen;

3. Recommended use of cable: 3 * 16 + 14, dust collection mouth: DN100 *

4. Lead Time: 60 Working days.
