1.Main parameter：

1.1. The total power of the machine is 16 kW, and the power supply is 380VAC 50HZ;

1.2. Spindle speed control motor: 0-3000 rpm, 4 kW;

1.3. Overall dimensions: 2100X2300X2000MM;

1.4. Maximum processing plate size: 1350X1250X80MM;

1.5. Fully automatic servo control of machining angle and bottom edge depth;

1.6. Applicable to processing of PET, PVC light wood, etc,

1.7. Chamfer range: saw blade type 0-60 degrees,

1.8. Processing tolerance: ± 0.5MM 1.9. Fully automatic control, human-machine dialogue, easy to operate, just input the product thickness.

2. Suggested use of cable: 3 * 10+1.

3. Dust collection port: DN100 * 2 pieces.

4. Lead time: 60 Working days.
