1. Main parameters：

1.1.Power Input: 40KW 380V.

1.2.Main shaft speed: 0-1440RPM (5x7.5KW).

1.3.Air pressure: 0.5-0.7MPa.

1.4.External Dimensions LxWxH: 4000mm x 2280mm x 1900mm.

1.5.Max. Sheet loaded LxWxH: 1220mm x 610mm x80mm.

1.6.Auto-adjustment to depth in line with thickness input.

1.7.Purpose: Balsa deep grooving.

2.Main configuration:

2.1.Gear e-reducer: Taiwan Shengbang 5 sets*7.5W

2.2.Low-voltage apparatus: 1 set*Schneider

2.3.Encoder: OMRON for digital control of all dimension

2.4.Lead screw slideway: Taiwan Shangyin 5 sets

2.5.Pneumatic control: Taiwan AirTAC 1 set

2.6.Knife blade：OD300*ID100*1.4T&OD270*ID100*1.4T ；

2.7.MITSUBISHI operation system

2.8.Power cable：3*25+1
